Saab and GMV are collaborating in ASGARD, an EU-funded undertaking that goals to enhance maritime safety when utilizing GNSS and OSNMA. The undertaking addresses the rising menace of GNSS spoofing and different cyberattacks on navigation programs used within the maritime business.
The ASGARD undertaking, run by Saab and GMV, is an formidable European Union (EU) initiative that goals to develop superior applied sciences to enhance Global Navigation Satellite System (GNSS) and Open Service Navigation Message Authentication (OSNMA) safety in maritime environments. The undertaking is a direct response to the rising menace of GNSS spoofing and different cyberattacks on navigation programs used within the maritime business. By leveraging cutting-edge expertise and experience, the ASGARD undertaking goals to deal with these challenges and enhance the protection and safety of maritime navigation programs throughout Europe and past.
GNSS is a essential expertise utilized in maritime navigation programs. It allows vessels to find out their place, pace, and time by receiving alerts from satellites orbiting the Earth. However, GNSS alerts are weak to interference and spoofing, which might trigger navigation programs to supply incorrect data. This can result in accidents and different security hazards, in addition to potential threats to nationwide safety.
The ASGARD undertaking seeks to develop superior applied sciences to detect and mitigate GNSS spoofing assaults in maritime environments. One of the important thing applied sciences being developed is OSNMA, which supplies a method of authenticating GNSS alerts to make sure that they’re real and haven’t been tampered with. By implementing OSNMA, navigation programs can present extra dependable and trusted positioning data to vessels, which improves security and effectivity within the maritime business.
E-warfare at Sea
In the late Nineties, the maritime business stakeholders constructed the principle Navigator, ECDIS, and AIS programs to enhance maritime security and safety. While the event and deployment of AIS within the final decade have considerably contributed to elevated navigational security, it has additionally led to a number of security and safety issues. One of the key points is spoofing, the place the vessel’s AIS information is manipulated.
According to a report by the Center for Advanced Defense Studies (C4ADS), Russia has been manipulating GNSS alerts since at the very least 2016. The report, primarily based on satellite tv for pc information collected by the International Space Station (ISS), recognized 9,883 suspected spoofing incidents in 10 world areas linked to the Russian army (Gary C. Kessler, CISSP DEFCON, 04/2019). The focused areas embrace the Black Sea, Crimea, the Russian Federation, and Syria. The examine found that 1,311 civilian ships had been supplied incorrect place coordinates from quite a lot of civilian satellite tv for pc networks, together with an incident within the Black Sea in 2017.
A brand new and cheap digital system has emerged in Asia that’s able to spoofing AIS alerts in ways in which consultants haven’t seen earlier than. This has resulted in a number of spoofing incidents being reported in over 20 coastal areas and ports, together with Shanghai, Fuzhou (Huilutou), Qingdao, Quanzhou (Shiyucun), Dalian, and Tianjin, which have been ongoing for months. Unlike conventional spoofing, the GNSS alerts had been gathered into giant circles, which had been later dubbed “crop circles.” The transferring alerts had been then shifted to the identical place, making a complicated visitors scenario for ship pilots. Due to the low value of GNSS spoofing expertise, these assaults are prone to unfold to different international locations, terrorist teams, criminals, and even particular person operators, posing a critical menace to maritime security.
Existing Countermeasures
What measures might be taken to detect GPS/GNSS spoofing? One methodology is to detect sign distortion on the level when the pretend sign overrides the respectable one. Another strategy is to find out that the pretend sign is originating from a special path than the respectable sign. Additionally, encrypted alerts might be correlated to confirm their authenticity, even when the civilian unit can’t interpret the encrypted sign. Employing a GNSS receiver that screens a number of constellations and frequencies with safety capabilities can be an possibility. Also, it’s doable to authenticate the Open Service Navigation Message by means of OSNMA performance.
Ultimately, enhanced cybersecurity is essential. GNSS spoofing has been a safety concern for a few years, and it’s now starting to considerably impression transport. As extra gadgets and autonomous programs depend upon GNSS, a better variety of programs might be inclined to spoofing assaults. With hackers frequently trying to find new methods to use AIS vulnerabilities and spoofing, there will probably be quite a few new cybersecurity vulnerabilities sooner or later, and programs that aren’t adequately secured will probably be susceptible to assault.
Image courtesy ASGARDExample Attacks
On the opposite hand, AIS, because it at present exists, has a number of vulnerabilities which have emerged, largely on account of being primarily based on an open-source system that operates on particular VHF frequencies. The 4 foremost weaknesses are the absence of message integrity, timing, authentication, and validity. If compromised, AIS communications might be intercepted to create fictitious vessels or generate false collision or SOS alerts, occasions that might have critical implications at sea. The vulnerabilities in GNSS programs additionally open the potential of assaults that might impression navigation and AIS-dependent applied sciences. Below are some examples of GPS spoofing assaults which were documented by authorities:
Hacking Scenarios
The vulnerabilities of programs as AIS might be exploited in numerous methods, relying on the kind of hack state of affairs. For occasion, within the closest level of strategy (CPA) spoofing, the attacker creates a misunderstanding of a doable collision with one other ship, inflicting a CPA alert that might lead the sufferer vessel off-course and into hazard. Another hack state of affairs is AIS Search and Rescue Transmitter (AIS-SART) spoofing, the place the attacker sends a pretend misery beacon to lure the sufferer vessel into an attacker-controlled space. A 3rd sort of spoofing assault is climate forecast spoofing, the place the attacker sends false dynamic climate data by way of AIS, making the sufferer ship alter its course.
Denial-of-Service (DoS) assaults are one other type of AIS spoofing that goals to overflow vessels’ AIS updates, flooding adjoining shore services and vessels with extreme information. There can be the frequency hopper assault, the place the attacker sends instructions to shift the sufferer vessel’s AIS to transmit on a particular frequency, making them “invisible” to all however the attacker.
Ghost vessels and information diddling are two different assault eventualities. In the previous, the attacker creates pretend vessels, whereas within the latter, the attacker modifies ship data similar to title, location, course, cargo, sort of ship, and pace. These assaults might be executed by way of software program onshore or inland, or by means of radio frequency (RF) offshore or at sea.
One main safety concern is the supply of AIS information on-line by means of numerous publicly accessible platforms. The IMO committee strongly recommends that nations take authorized measures to guard information from being revealed, as such publicity might severely compromise security at sea.
Acquiring the tools required to spoof GNSS alerts is each low cost and uncomplicated. In the occasion of GPS, civilian alerts aren’t encrypted (L1C, L2C, L5). All that’s wanted is a Software-defined radio (SDR) able to transmitting on L1 frequency (1575.42 MHz). With the help of open-source instruments, it’s simple to jot down a program that may generate GPS NMEA sentences and transmit them by means of SDR for GPS spoofing functions.
ASGARD – Protection by Detection
Saab and GMV have collaborated to develop ASGARD, a expertise to counter ongoing GNSS spoofing actions. This joint effort combines capabilities into an efficient answer capable of detect spoofing assaults and alert the crew, permitting them to take essential actions to validate their place. ASGARD, an acronym for Advanced Shipborne Galileo Receiver Double Frequency, is an anti-spoofing GNSS receiver that’s primarily based on the open service of Europe’s Galileo satellite tv for pc navigation system. This receiver is designed to obtain alerts from a number of constellations, and it complies with European and worldwide laws. ASGARD makes use of Galileo’s Open Service Navigation Message Authentication (OSNMA) mechanism to authenticate the navigation message, and it has been co-funded by the European Union Agency for the Space Program (EUSPA). The intention of this undertaking is to extend the adoption of Galileo in maritime transport by growing shipborne EGNSS data-processing receivers that may detect and alert vessels which are below spoofing assaults.
Galileo’s Open Service Navigation Message Authentication (OSNMA) is a element of the end-to-end authentication system for Galileo’s civilian navigation alerts. This function permits Galileo satellites to ship a key and digital signature that the ASGARD receiver can use to confirm the authenticity of the sign utilizing its personal public key. If the ASGARD receiver detects a sign that may’t be authenticated, it’s going to alert the operator of a possible spoofing assault and immediate them to take different measures to validate the vessel’s place.
ASGARD additionally provides an progressive integrity answer, guaranteeing the reliability and security of the system. The use of OSNMA together with this superior integrity answer makes ASGARD the primary licensed safety and security strategy, compliant with SOLAS and IEC laws for maritime security.
According to Ana Cezón, Head of Advance Navigation Division at GMV, ASGARD operates by utilizing a safety by detection technique. It is a one-of-a-kind security system that augments the safety ingredient of present Navigation and AIS options. Using Galileo’s OSNMA, the system supplies an important validation and authentication of message integrity for secure maritime navigation. ASGARD’s progressive integrity function enhances the protection of maritime customers and units the stage for the long run strategy to maritime security. It is just a really strong and dependable navigation answer, concludes Ana Cezón.
ASGARD is a multi-feature expertise together with the next functionalities:
Multi-GNSS receiver: ASGARD makes use of a number of GNSS constellations, similar to GALILEO and GPS, to supply redundant positioning choices. This function improves navigation efficiency, and if one constellation is jammed, spoofed, or not usable, the receiver can change to a different.
The accelerated use of digital applied sciences poses a major menace to security and safety at sea. As highlighted on this article there are an immense variety of vectors for assault. To preserve the integrity of vessels, it’s essential to implement robust cyber safety programs similar to ASGARD, which supplies lively protection towards spoofing.
Combined Capabilities
ASGARD is the results of a collaboration between GMV and Saab, two main corporations with a long-standing popularity within the subject of maritime communication and navigation. By combining GMV’s newest technology Galileo receiver and Saab’s well-proven navigation system, ASGARD provides a strong protection towards cyber-attacks that intention to intrude with the navigation programs of vessels. Spoofing is a critical menace to vessel integrity and might have extreme penalties, similar to collisions and groundings. ASGARD supplies an efficient response to those assaults by guaranteeing that vessels keep heading in the right direction and aren’t lured off by attackers. With ASGARD, vessel house owners and operators can have peace of thoughts understanding that their vessels are geared up with cutting-edge expertise that gives safety towards cyber-attacks and helps guarantee the protection and safety of the crew and cargo.
Peter Bergljung, Head of Strategy at Saab AB (publ) TransponderTech, underscores Saab’s dedication to making sure the protection of everybody, together with seafarers, who should really feel secure and safe at sea. He affirms that the event of ASGARD is a devoted effort by Saab and GMV, and the system is absolutely compliant with IMO, IEC, and MED requirements.
Real-time testing will probably be a essential step within the improvement of ASGARD, the place the system will probably be put by means of a sequence of spoofing assaults to make sure it delivers inside set specs. This testing is essential to make sure that ASGARD can present dependable and efficient safety towards the most recent spoofing strategies which may be utilized by cyber attackers.
The ASGARD undertaking is a vital step ahead within the improvement of sturdy and dependable cyber safety programs for the maritime business. Once launched, ASGARD is anticipated to have a major impression on the maritime business, enhancing security and safety for vessels and crews. It can be anticipated to spice up the uptake of Galileo within the maritime sector, when ASGARD is licensed in accordance with maritime security laws (SOLAS) and maritime requirements (IEC).
